RAM 30K Square Gooseneck Coupler – Top Wind – GCSQTW-30008

RAM 30K Square Gooseneck Coupler – Top Wind – GCSQTW-30008

The RAM GCSQTW-30008 Square Gooseneck Coupler is a heavy-duty 30,000 lb capacity coupler designed for gooseneck equipment trailers, flatbeds, heavy-haulers, and other commercial trailer applications.

The square-tube design features a top-wind adjustment handle, load-bearing pin, and heavy-duty cast coupler head designed to provide a strong, secure connection to a 2-5/16" gooseneck ball.

Specifications

• Part Number: GCSQTW-30008
• Capacity: 30,000 lbs
• Ball Size: 2-5/16"
• Coupler Style: Square Tube Gooseneck
• Outer Tube Size: 4.5" Square
• Retracted Height: 32"
• Vertical Adjustment: 7"
• Adjustment Type: Top Wind
• Mounting: Weld-On
• Finish: Raw Steel
• Safety: Load-Bearing Pin

Features

• Heavy-duty 30K trailer capacity
• Top-wind crank for easy height adjustment
• One-piece cast coupler head
• Curved internal ball clamp for a secure fit
• Hidden spring latch mechanism helps protect moving components
• Welded belly band reinforces the bottom of the outer tube
• Load-bearing pin for heavy-duty trailer applications

Applications

Ideal for:

• Gooseneck Trailers
• Equipment Trailers
• Tandem Dual Trailers
• Flatbed Trailers
• Dump Trailers
• Heavy-Hauler Trailers
• Commercial Trailers

Important

30,000 LB CAPACITY – 2-5/16" GOOSENECK BALL

Verify the GCSQTW-30000 / GCSQTW-30008 part number, 4.5" square tube size, 2-5/16" ball size, and trailer requirements before ordering or installation.
