RAM 12,000 lb support / 10,000 lb lift capacity direct-weld square trailer jack with front-pull spring-loaded drop leg and a side-wind crank TJD 12000 SP-F

RAM 12K Direct-Weld Square Trailer Jack – 10K Lift Capacity – TJD-12000SP-F

The RAM TJD-12000SP-F Square Trailer Jack is a heavy-duty, direct-weld jack designed for commercial, equipment, dump, and other heavy-duty trailers. It provides a 10,000 lb lifting capacity and 12,000 lb support capacity, with a spring-loaded drop leg for fast height adjustment.

The front-pull drop-leg release provides convenient access to the spring-loaded drop leg, while the side-wind crank offers smooth manual operation. Its heavy-duty 4" square tube construction and direct-weld mounting design provide a strong, permanent installation on the trailer frame.

Key Specifications

• Part Number: TJD-12000SP-F
• Brand: RAM
• Lift Capacity: 10,000 lbs
• Support Capacity: 12,000 lbs
• Crank Style: Side-Wind
• Crank Travel: Approximately 12.5"
• Drop-Leg Travel: Approximately 13.5"
• Retracted Height: 28"
• Extended Height: 40.25"
• Total Adjustment: Up to approximately 25.8" with drop leg
• Tube Size: 4" Square
• Mounting: Direct Weld-On

Features

Front-Pull Spring-Loaded Drop Leg
The front-facing pull pin releases the spring-loaded drop leg, allowing quick manual height adjustments before using the crank.

Heavy-Duty Direct-Weld Design
Designed to weld directly to the trailer frame for a strong, permanent installation suitable for demanding trailer applications.

Side-Wind Crank
Side-mounted crank provides convenient operation and controlled lifting and lowering.

Grease Zerk for Easy Maintenance
A built-in grease fitting makes it easy to lubricate the internal jack screw and gears, helping maintain smooth operation and extend jack life.

Ideal For

Heavy-duty equipment trailers, dump trailers, gooseneck trailers, commercial trailers, and other applications requiring a high-capacity square trailer jack.
