15K Left-Hand Electric Brake Assembly 12-1/4" x 5" – Dexter K23-446-00

Dexter 15K Left-Hand Electric Brake Assembly 12-1/4" x 5" – K23-446-00

The Dexter K23-446-00 Left-Hand Electric Brake Assembly is a heavy-duty replacement brake designed for 15,000 lb Dexter trailer axles. This complete 12-1/4" x 5" electric brake assembly features a forward self-adjusting design and heavy-duty backing plate for demanding trailer applications.

Specifications

• Dexter Part Number: K23-446-00
• Brake Assembly Number: 023-446-00 / 23-446
• Axle Capacity: 15,000 lbs
• Brake Size: 12-1/4" x 5"
• Position: Left Hand / Driver Side
• Brake Type: Electric Drum Brake
• Adjustment: Forward Self-Adjusting
• Mounting Pattern: 7-Bolt
• Application: Heavy-Duty Trailer Axle

Left-Hand / Driver-Side Brake

This is the LEFT-HAND brake assembly, which installs on the driver side of the trailer.

Application

Designed for compatible Dexter 15K heavy-duty trailer axles using 12-1/4" x 5" electric drum brakes.

Common applications include:

• Heavy-Duty Equipment Trailers
• Gooseneck Trailers
• Dump Trailers
• Commercial Trailers
• Heavy-Hauler Trailers

Related Parts

• Right-Hand / Passenger-Side Brake: Dexter K23-447-00
• Brake Drum: Dexter 009-028-01

Important

LEFT-HAND / DRIVER-SIDE BRAKE ONLY.

For the opposite side, use the Dexter K23-447-00 Right-Hand / Passenger-Side Brake Assembly.

Verify the K23-446-00 part number, axle capacity, 12-1/4" x 5" brake size, and 7-bolt mounting pattern before ordering.
