HDSS Torque Arm / Radius Rod Bushing – 1" ID x 3" Long SH1001

$19.99
Shipping calculated at checkout.

HDSS Torque Arm / Radius Rod Bushing – 1" ID x 3" Long SH1001

The HDSS Torque Arm Bushing is a heavy-duty replacement suspension bushing designed for compatible HDSS and Hutchens-style trailer suspension systems. The bushing installs in the torque arm / radius rod and provides the mounting point for the suspension bolt while helping absorb movement and vibration.

Specifications

  • Application: Heavy-Duty Trailer Suspension
  • Bushing Type: Torque Arm / Radius Rod Bushing
  • Inner Diameter (ID): 1"
  • Outer Diameter (OD): Approximately 1-15/16"
  • Length: 3"
  • Application: HDSS / Hutchens-Style Suspension

Compatibility

Used on compatible heavy-duty trailer suspension systems including:

  • Hutchens H7700
  • Hutchens CH7700
  • Hutchens H9700
  • Hutchens CH9700
  • HDSS-Style Heavy-Duty Trailer Suspensions

Related Hardware

  • Torque Arm Bolt: SH1026
  • Bolt Size: 1"-14 x 5"
  • Flanged Locknut: SH1027
  • Nut Size: 1"-14

Ideal for replacing a worn, cracked, loose, or damaged torque arm bushing when servicing heavy-duty trailer suspension systems.

Important: Verify the bushing dimensions and suspension configuration with your existing HDSS suspension before ordering.
