12K Dexter Disc Brake Hub – 8 on 6.5" – 008-214-10

Dexter 12K Disc Brake Hub – 8 on 6.5" – 008-214-10

The Dexter 008-214-10 Hub is a heavy-duty replacement hub designed for compatible 12,000 lb trailer axles, including hydraulic disc brake applications.

This is the hub with wheel studs and bearing races only, making it ideal when rebuilding or servicing an existing 12K disc brake hub assembly.

Specifications

• Dexter Part Number: 008-214-10
• Alternate Number: 8-214-10
• Axle Capacity: 12,000 lbs per pair
• Application: 12K Trailer Axle / Disc Brake Hub
• Bolt Pattern: 8 on 6.5"
• Lubrication: Oil Bath
• Hub Pilot Diameter: 4.75"
• Wheel Compatibility: 16" & 16.5"
• Inner Bearing: 3984
• Outer Bearing: 28682

Includes

• (1) Hub
• Wheel Studs
• Inner & Outer Bearing Races

Not Included

Bearings, oil seal, oil cap, lug nuts, rotor, and brake components are not included unless specifically stated.

Application

Designed for compatible 12K heavy-duty trailer axle hub and hydraulic disc brake systems.

Common applications include:

• Equipment Trailers
• Gooseneck Trailers
• Tandem Dual Trailers
• Heavy-Hauler Trailers
• Commercial Trailers

Important

HUB WITH STUDS AND RACES ONLY.

Verify the 008-214-10 part number, 8 on 6.5" bolt pattern, bearing combination, and existing disc brake configuration before ordering.
