12K Dexter Axle 74" x 46" with Hydraulic Disc Brakes

Dexter 12K Trailer Axle 74" x 46" with Hydraulic Disc Brakes

The Dexter 12,000 lb Trailer Axle with Hydraulic Disc Brakes is a complete heavy-duty axle assembly designed for equipment trailers, gooseneck trailers, commercial trailers, and other demanding applications.

This axle features a 74" hub-face measurement, 46" spring-center measurement, and heavy-duty hydraulic disc brakes for dependable braking performance.

Specifications

• Brand: Dexter
• Axle Capacity: 12,000 lbs
• Hub Face: 74"
• Spring Center: 46"
• Brake Type: Hydraulic Disc Brakes
• Axle Tube: 5" Round
• Bolt Pattern: 8 on 6.5"
• Wheel Stud Size: 5/8"
• Lubrication: Oil Bath
• Spring Seat Width: 3"
• Spring Type: Designed for Compatible 3" Wide Slipper Springs

Disc Brake Components

• Hub: Dexter 008-214-10
• Rotor: Dexter 070-006-01
• Brake Caliper: Dexter 089-002-02
• Inner Bearing: 3984
• Outer Bearing: 28622
• Inner Race: 3920
• Outer Race: 28682
• Oil Seal: 010-056-00

Application

Designed for heavy-duty trailer applications requiring a 12K Dexter axle with hydraulic disc brakes, including:

• Equipment Trailers
• Gooseneck Trailers
• Tandem Dual Trailers
• Heavy-Hauler Trailers
• Commercial Trailers

Important

12,000 LB COMPLETE AXLE WITH HYDRAULIC DISC BRAKES.

Verify the 74" hub face, 46" spring center, 8 on 6.5" bolt pattern, spring configuration, and brake requirements with your existing trailer before ordering.

Springs and U-bolt kits are not included unless specifically stated.
