10K–15K Disc Brake Rotor Mounting Stud – 1/2"-13 x 1/2"-20 – Dexter 025-014-00

10K–15K Disc Brake Rotor Mounting Stud – 1/2"-13 x 1/2"-20 – Dexter 025-014-00

Description
The Dexter 025-014-00 Rotor Mounting Stud is a genuine Dexter double-ended screw-in stud designed for compatible heavy-duty trailer hydraulic disc brake systems. It features a 1/2"-13 coarse thread on the hub side and a 1/2"-20 fine thread on the nut side.

Measuring approximately 2.53" overall length, this stud is used to securely mount the disc brake rotor to the hub on compatible 10K, 12K, and 15K Dexter heavy-duty trailer axles.

This mounting stud is designed to go with the Dexter 070-006-01 Disc Brake Rotor and the Dexter 006-046-00 1/2"-20 Flange Nut. Rotor and flange nut are not included and are sold separately.

Key Features

• Application: Dexter 10K–15K hydraulic disc brake axles
• Part Number: Dexter 025-014-00
• Type: Double-Ended Screw-In Rotor Mounting Stud
• Hub-Side Thread: 1/2"-13 coarse thread
• Nut-Side Thread: 1/2"-20 fine thread
• Overall Length: Approximately 2.53"
• Designed to secure compatible disc brake rotors to the hub
• Genuine Dexter replacement component
• Designed for heavy-duty hydraulic disc brake applications

Brand: Dexter
Part Number: 025-014-00
Hub Thread: 1/2"-13
Nut Thread: 1/2"-20
Length: Approximately 2.53"
Application: 10K–15K Hydraulic Disc Brakes
Sold Individually: 1 Mounting Stud
