15K Right-Hand Electric Brake Assembly 12-1/4" x 5" – Dexter K23-447-00

Dexter 15K Right-Hand Electric Brake Assembly 12-1/4" x 5" – K23-447-00

The Dexter K23-447-00 Right-Hand Electric Brake Assembly is a heavy-duty replacement brake designed for 15,000 lb Dexter trailer axles. This complete 12-1/4" x 5" electric brake assembly features a forward self-adjusting design and heavy-duty backing plate for demanding trailer applications.

Specifications

• Dexter Part Number: K23-447-00
• Brake Assembly Number: 023-447-00 / 23-447
• Axle Capacity: 15,000 lbs
• Brake Size: 12-1/4" x 5"
• Position: Right Hand / Passenger Side
• Brake Type: Electric Drum Brake
• Adjustment: Forward Self-Adjusting
• Mounting Pattern: 7-Bolt
• Application: Heavy-Duty Trailer Axle

Right-Hand / Passenger-Side Brake

This is the RIGHT-HAND brake assembly, which installs on the passenger side of the trailer.

For the opposite side, use the Dexter K23-446-00 Left-Hand / Driver-Side Brake Assembly.

Application

Designed for compatible Dexter 15K heavy-duty trailer axles using 12-1/4" x 5" electric drum brakes.

Common applications include:

• Heavy-Duty Equipment Trailers
• Gooseneck Trailers
• Dump Trailers
• Commercial Trailers
• Heavy-Hauler Trailers

Important

RIGHT-HAND / PASSENGER-SIDE BRAKE ONLY.

For the opposite side, use the corresponding left-hand / driver-side brake assembly.

Verify the K23-447-00 part number, 15K axle capacity, 12-1/4" x 5" brake size, and 7-bolt mounting pattern before ordering.
